100m Roll Flame Retardant Tube Red Clear Teflon Insulated Wire

Brand Name:	Long
Model Number:	PTFE-1
MOQ:	100m
Payment Terms:	T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability:	400000/per day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001

Material:

PTFE Teflon

Color:

Clear And Red

Length:

100m/roll

Standard:

ROHS

Size:

As Order

Feature:

Insulation

Certificate:

ISO9001

Size AWG30:

0.30±0.10mm

Packaging Details:

carton/pallet

Supply Ability:

400000/per day

Highlight:

100m roll flame retardant tube

red flame retardant tube

Clear Teflon Insulated Wire

Product Description

Clear Red PTFE High Temperature Insulated And Flame Retardant Tube

PTFE Teflon tubing

Specially designed for protecting applications in extreme electrical Chemical and thermal environment.

Features

● Chemical insert

● High temperature resistance

● Continuous operating

● Temperature:-80℃- 200℃

● Corrosion resistance(acid/alkali resistance, chemical reagents oil-proof)

● High pressure resistance

● Standard: UL224 VW-1 C-UL CSA22.20FT

● UL file number: E203950

Dimensions

Size AWG	Expanded	External Diameter			Standard Package M/Spool
Size AWG	Internal Diameter mm	(S)	(T)	(L)	Standard Package M/Spool
30	0.30±0.10	0.80±0.10	0.70±0.10	0.60±0.10	305
28	0.38±0.10	0.88±0.10	0.78±0.10	0.68±0.10	305
26	0.46±0.10	0.96±0.10	0.86±0.10	0.76±0.10	305
24	0.56±0.10	1.16±0.10	1.06±0.10	0.86±0.10	305
23	0.66±0.10	1.26±0.10	1.16±0.10	0.96±0.10	305
22	0.71±0.10	1.31±0.10	1.21±0.10	1.01±0.10	305
21	0.81±0.10	1.41±0.10	1.31±0.10	1.11±0.10	305
20	0.86±0.10	1.66±0.10	1.46±0.10	1.16±0.10	305
19	0.96±0.20	1.76±0.20	1.56±0.20	1.26±0.20	200
18	1.07±0.20	1.87±0.20	1.67±0.20	1.37±0.20	200
17	1.19±0.20	1.99±0.20	1.79±0.20	1.49±0.20	200
16	1.34±0.20	2.14±0.20	1.94±0.20	1.64±0.20	153
15	1.50±0.20	2.30±0.20	2.10±0.20	1.80±0.20	153
14	1.68±0.20	2.48±0.20	2.28±0.20	2.08±0.20	100
13	1.93±0.20	2.73±0.20	2.53±0.20	2.33±0.20	100
12	2.16±0.25	2.96±0.25	2.76±0.25	2.56±0.25	100
11	2.41±0.25	3.21±0.25	3.01±0.25	2.81±0.25	150
10	2.86±0.25	3.49±0.25	3.29±0.25	3.09±0.25	150
9	3.00±0.25	4.00±0.25	3.80±0.25	3.40±0.25	150
8	3.38±0.25	4.38±0.25	4.18±0.25	3.78±0.25	100
7	3.76±0.25	4.76±0.25	4.56±0.25	4.16±0.25	100
6	4.22±0.25	5.22±0.25	5.02±0.25	4.80±0.25	100
5	4.72±0.25	5.72±0.25	5.52±0.25	5.32±0.25	50
4	5.28±0.30	6.28±0.30	6.08±0.30	5.88±0.25	50
3	5.94±0.30	6.94±0.30	6.74±0.30	6.54±0.25	1.00
2	6.68±0.30	7.68±0.30	7.48±0.30	7.28±0.25	1.00
1	7.46±0.30	8.46±0.30	8.26±0.30	8.06±0.25	1.00
0	8.38±0.30	9.38±0.30	9.18±0.30	8.98±0.25	1.00

Technical Data

Property	Method Test	Stantard
Tensile Strengtn(MPa)	ASTMD 2671	≥25
Elongation(%)	ASTMD 2671	≥300
Flammablity	VW-1	Pass
Dieletric strength(kv/mm)	IEC 60243	≥26
Volume resistivity(Ω.cm)	ASTM D876	≥1X1014
