5m PTFE tube with high temperature resistance, chemical resistance, and electrical insulation for industrial applications

Brand Name:	None
Model Number:	1,9mm*5M
MOQ:	5
Price:	0.7
Payment Terms:	T/T
Supply Ability:	10000 meters day

Detail Information

Product Description

Detail Information

Place of Origin:

Jangsu China

Certification:

ISO9001

Material:

PTFE

Color:

Black ,red ,yellow ,blue ,clear ,brown ,pink ,purple Etc.

Trait:

Non Shrinkable

Temperature Operating:

-190°C To 260°C

Chemical Resistance:

All Acid ,alkali ,solvent And Oil Resistance

Resistance:

Water ,ozone ,UV Resistance ,non-aging

Wear Resistance:

Non-stick ,low Coefficient Of Friction

Electrical Insulation:

High Electrical Insulation And High Dielectric Strength

Volume Resistivity:

≥1x10^18Ω·cm

Dielectric Constant:

Almost 2.1

Tensile Strength:

≥13.7N/mm

Elongation Break:

Over 200%

Flexibility:

Good

Flammability:

UL94, V-0 ,self-extinguishing

Packaging Details:

carton

Supply Ability:

10000 meters day

Highlight:

5m PTFE tube high temperature resistance

PTFE tube chemical resistance industrial

electrical insulation PTFE tubing

Product Description

Description :

Non-shrink PTFE tube is extruded from high-quality PTFE resin with no heat shrinkable property ,stable dimension and high mechanical strength . It features excellent high and low temperature resistance ,corrosion resistance and high insulation performance .Colored types are available for line identification ,widely used in harsh conditions such as electrical ,chemical ,medical and aerospace fields.

Key Feature :

Stable material ,non-shrinking and non-deforming ,high dimensional accuracy.

Operating temperature :-190 to 260 °C

Excellent chemical resistance to strong acids ,alkalis ,organic solvent and oils

Excellent electrical insulation ,low dielectric loss ,high insulation strengh

Low friction ,non-stick ,anti-aging ,weather resistant and UV resistant

Non-toxic and eco-friendly ,compliant with RoHS ,REACH ,partly FDA compliant

Various colors available for easy line identification

Typical applications :

Insulation sleeces for high frequency signal wires ,coaxial cables and sensors

Harness identification ,wire protection and terminal insulation

Protection tubes for transformers ,capacitors ,connectors and PCB circuits

Transfer tubes for highly corrosive chemicals and gases

Laboratory tubing ,analytical instruments and chromatograph catheters

Oil pumps ,hydraulic systems and oil and corrosion resistant sleeves

Medical catheters ,endoscope protection tubes and presion instrument sheaths

Hygienic transfer tubes for food ,beverage and filling equipment

Heat insulation tubes for engine wiring harnesses ,anti-corrosion tubes for fuel systems

Aerospace instrument wiring ,hydraulic pipelines and high temperature wire protection

5m PTFE tube with high temperature resistance, chemical resistance, and electrical insulation for industrial applications 0
