Green Single Wall Heat Shrink Tubing

Name: Green Single Wall Heat Shrink Tubing
Brand: Changzhou Longchuang Insulating Material Co., Ltd.
SKU: 8.0mm
Price: 0.02 USD
Availability: InStock

Brand Name:	Long
Model Number:	8.0mm
MOQ:	1m
Price:	Can discussible
Payment Terms:	T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability:	400000meters per day

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO

Color:

Light Green

Size:

8mm

Shrink Ratio:

2:1

Wall:

Ultra Thin Wall

Flexible:

Flexible

Halogen:

Halogen Free

Retardant:

Flame Retardant

Compliant:

RoHS And Sony Compliant

Packaging Details:

Roll/Carton

Supply Ability:

400000meters per day

Highlight:

green Single Wall Heat Shrink Tubing

8.0mm Single Wall Heat Shrink Tubing

1" waterproof shrink tube

Product Description

8mm Light Green Heat Shrink Tubing With Shrink Ratio 2X Waterproof Insulating Tube

Ultra thin wall halogen free.flexible

heat shrink tubing.

Features

• Ultra thin wall

• Flexible

• Halogen free

• Flame retardant

• low smoke generation if burning

• Continuous operating Temperature:-55°C to 125°C

• Fully shrink temperature: 110°C

• RoHS and Sony compliant

Dimensions

Size		As Supplied	After Recovery		Standard Package
Inch	mm	Internal Diameter mm	Internal Diameter mm	Wall Thickness mm	Spool Length M/spooF
1/16	1.0	1.4±0.2	0.65	0.20	200
	1.5	1.9+0.2	0.85	0.20	200
3/32	2.0	2.4±0.2	1.00	0.22	200
	2.5	2.9±0.2	1.30	0.25	200
1/8	3.0	3.4±0.2	1.50	0.28	200
	3.5	3.9±0.2	1.80	0.28	200
	4.0	4.410.2	2.00	0.30	200
3/16	4.5	4.9±0.2	2.30	0.30	100
	5.0	5.5±0.2	2.5	0.32	100
1/4	6.0	6.5±0.2	3.0	0.32	100
5/16	7.0	7.5±0.3	3.5	0.32	100
	8.0	8.5±0.3	4.0	0.32	100
3/8	9.0	9.5+0.3	4.5	0.35	100
	10.0	10.5±0.3	5.0	0.35	100
	11.0	11.5±0.3	5.5	0.40	100
1/2	12.0	12.5±0.3	6.0	0.40	100
	13.0	13.5±0.3	6.5	0.40	100
	14.0	14.5±0.3	7.0	0.40	100
5/8	15.0	15.5±0.4	7.5	0.40	100
	16.0	16.5±0.4	8.0	0.40	100
	17.0	17.5±0.4	8.5	0.40	100
3/4	18.0	18.5±0.4	9.0	0.42	100
	20.0	20.5±0.5	10.0	0.45	100
	22.0	22.5±0.5	11.0	0.45	100
1	25.0	25.5±0.5	12.5	0.45	50

Technical Data

I Property I	Test Method	Typical Performance I
Tensile strength(MPa)	ASTM D 2671	>10.4
Ultimate elongation(%)	ASTM D 2671	>200
Tensile strength after heat aged (Mpa)	158°CX168h	N7.3
Ultimate elongation after heat aged (%)	158°CX168h	^100
Longitudinal change(%)	ASTM D 2671	-5%~+5%
Flammability	ASTM D 2671 C method	VW-1
Dielectric strength (kV/mm)	ASTM D 149	>15
Volume resistivity (Q-cm)	ASTM D 876	^10¹⁴
