3 To 1 3.2mm Red Shrink Wrap Tubing 110C 110C Flexible Heat Shrink Tubing

  • 3 To 1 3.2mm Red Shrink Wrap Tubing 110C 110C Flexible Heat Shrink Tubing
  • 3 To 1 3.2mm Red Shrink Wrap Tubing 110C 110C Flexible Heat Shrink Tubing
Place of Origin China
Brand Name Long
Certification ISO
Model Number SBRS-(3X)GLW
Minimum Order Quantity 10m
Packaging Details Roll/Carton
Delivery Time 1-10days
Payment Terms T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability 500000meter per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material PE Colour Black
Feature Flexible Wall Thickness Thick Adhesive
Shrink Ratio 3:1 Min Shrink Temperature 110
Total Wall Thickness Mm 0.90±0.30 Adhesive Thickness Mm 0.45±0.20
Highlight

3 to 1 red shrink wrap tubing

,

3.2mm red shrink wrap tubing

,

110C flexible heat shrink tubing
Leave a Message
Product Description



1/8 3.2mm Red Flexible, Thick Adhesive-Lined Dual Wall Heat Shrink Tubing



Flexible, Thick Adhesive-Lined Dual Wall Heat-ShrinkTubing is manufactured by co-extrusion of polyolefin and hot-melt adhesive. Designed to provide both insulation and sealing for protected articles, Used to protect bundles wires and metal tubes against water and moisture.



Features



Low longitudinal shrinkage

Thick adhesive liner bonding to a wide variety of plastics

ubber and metals forms an effective barrier against fluids

Flexible

Continuous operating temperature:-45°C-125°C

Min shrinktemperature:110°C

Shrink ratio: 3:1



Dimensions




Inch mm Internal Diameter mm Internal Diameter mm Total Wall Thickness mm

Adhesive

Thickness mm

 Spool Length M/spool
1/8 3.2 3.2 1.0 0.90±0.30 0.45±0.20 200
3/16 4.8 4.8 1.6 1.20±0.30 0.55±0.20 100
1/4 6.4 6.4 2.2 1.25±0.30 0.55±0.20 100
5/16 7.9 7.9 2.7 1.35±0.30 0.65±0.20 100
3/8 9.5 9.5 3.2 1.35±0.30 0.65±0.20 50
1/2 12.7 12.7 4.2 1.55±0.40 0.75±0.20 1.22OR25M/Roll
5/8 15.0 15.0 5.2 1.65±0.40 0.75±0.20 1.22OR25M/Roll
3/4 19.1 19.1 6.3 1.90±0.40 0.85±0.20 1.22OR25M/Roll
1 25.4 25.4 8.5 2.00±0.40 0.90±0.20 1.22OR25M/Roll
5/4 30.0 30.0 10.2 2.05±0.40 0.90±0.20 1.22OR25M/R0II
1-1/2 38.1 38.1 13.5 2.35±0.40 1.05±0.20 1.22OR25M/R0II



Technical Data



I Property Test Method Standard Typical Performance I
Tensile Strength(MPa) ASTM D2671 >10.4 11
Elongation(%) ASTM D2671 >300 450
Tensile Strength after aging (MPa) UI224 158°CX168hr N7.3 8.5
Elongation after aging(%) UI224 158°CX168hr N200 350
Dieletric strength(kV/mm) IEC 60243 315 17.5
Volume resistivity(n.cm) IEC 60093 >1X1014 2.5X1014



Adhesive



Property Test Method Standard I
Water Absorption ASTM D570 v0.2%
Sofening Point(°C) ASTM E28 90±5
Strength of pearing(PE) ASTM D 1000 120N/25mm
Strength of pearing(AL) ASTM D 1000 80N/25mm



3 To 1 3.2mm Red Shrink Wrap Tubing 110C 110C Flexible Heat Shrink Tubing 0
