Flame Retardant Adhesive-Lined Heavy Wall Cross Linked Polyolefin Heat Shrink Tubing

  • Flame Retardant Adhesive-Lined Heavy Wall Cross Linked Polyolefin Heat Shrink Tubing
  • Flame Retardant Adhesive-Lined Heavy Wall Cross Linked Polyolefin Heat Shrink Tubing
Place of Origin China
Brand Name Long
Certification ISO
Model Number 9.0mm
Minimum Order Quantity 1m
Packaging Details Roll/Carton
Delivery Time 1-9days
Payment Terms MoneyGram, Western Union, T/T, D/P, D/A, L/C
Supply Ability 400000meters per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material PE Colour Black
Shrink Ratio 3:1 Protect Rugged Mechanical Protection
Size 6.0mm Water Absorption ≤0.2%
Shrinking Temperature 125℃ Continuous Operating Temperature -45℃- 125℃
Leave a Message
Product Description

Flame Retardant Adhesive-Lined Heavy Wall Cross Linked Polyolefin Heat Shrink Tubing



Adhesive-lined heavy wall heat shrink tubing insulates and protects electrical splice and terminations where maximum flame retardancy and exceptional insulating and sealing characteristics are required



Features



●  3:1 shrink ratio

●  Seal and protect cable splice and terminations

●  Rugged mechanical protection

●  Complete moisture sealing

●  Strain relief for delicate wire connections

●  High resistance to impact and abrasion

●  Thermoplastic adhesive liner for complete environmental protection and insulation

●  Continuous operating temperature:-45℃- 125℃

●  Shrinking temperature: 125℃

●   RoHS conplian



Dimensions



Size Expanded After Recovery

Standard Package

M/pc
  Internal Diameter mm Internal Diameter mm Jacket Thickness mm Adhesive Thickness mm Total Wall Thickness mm
6.0/2.0 6.0 2.0 1.40±0.20 0.45±0.10 1.85±0.25 1.22
8.0/2.0 8.0 2.0 1.40±0.20 0.45±0.10 1.85±0.25 1.22
10.2/3.0 10.2 3.0 1.40±0.20 0.50±0.10 1.90±0.25 1.22
12.0/3.0 12.0 3.0 1.40±0.20 0.50±0.10 1.90±0.25 1.22
16.0/5.0 16.0 5.0 1.50±0.20 0.55±0.15 2.15±0.30 1.22
19.1/5.6 19.1 5.6 1.80±0.20 0.60±0.15 2.40±0.30 1.22
22.0/6.0 22.0 6.0 2.00±0.30 0.60±0.15 2.60±0.30 1.22
25.0/8.0 25.0 8.0 2.00±0.30 0.60±0.15 2.70±0.30 1.22
28.0/6.0 28.0 6.0 2.40±0.30 0.95±0.20 3.30±0.35 1.22
33.0/8.0 33.0 8.0 2.50±0.30 0.80±0.15 3.30±0.35 1.22
38.1/12.0 38.1 12.0 2.40±0.30 0.80±0.15 3.30±0.35 1.22
43.2/12.7 43.2 12.7 2.50±0.30 0.80±0.15 3.30±0.35 1.22
55.0/16.0 55.0 16.0 2.50±0.30 0.80±0.15 3.30±0.35 1.22
65.0/19.0 65.0 19.0 2.50±0.30 0.80±0.15 3.30±0.35 1.22
75.0/22.0 75.0 22.0 2.90±0.30 0.80±0.15 3.70±0.40 1.22
85.0/25.0 85,0 25.0 2.90±0.30 0.80±0.15 3.70±0.40 1.22
95.0/30.0 95,0 30.0 3.00±0.30 0.80±0.15 3.80±0.40 1.22
115.0/34.0 115,0 34.0 3.00±0.30 0.80±0.15 3.80±0.40 1.22
140.0/42.0 140,0 42.0 3.00±0.30 0.80±0.15 3.80±0.40 1.22
160.0/50.0 160,0 50.0 3.10±0.30 0.80±0.15 3.90±0.40 1.22
180.0/65.0 180,0 65.0 3.10±0.30 0.80±0.15 3.90±0.40 1.00
200.0/69.0 200,0 69.0 3.10±0.30 0.80±0.15 3.90±0.40 1.00
230.0/78.0 230,0 78.0 3.10±0.30 0.80±0.15 3.90±0.40 1.00



Flame Retardant Adhesive-Lined Heavy Wall Cross Linked Polyolefin Heat Shrink Tubing 0Technical Data
Property Test Method Stantard
Water Absorption ASTM D570 ≤0.2%
Sofening Point(℃) ASTM E28 90±5
Strength of pearing(PE) ASTM D 1000 120N/25mm
Strength of pearing(AL) ASTM D 1000 80N/25mm



Flame Retardant Adhesive-Lined Heavy Wall Cross Linked Polyolefin Heat Shrink Tubing 1
